Description
| Processor | Intel Core i3-1005G1 (2C / 4T, 1.2 / 3.4GHz, 4MB) |
| Graphics | Integrated Intel UHD Graphics |
| Chipset | Intel SoC Platform |
| Memory | 1x 8GB SO-DIMM DDR4-2666 |
| Memory Slots | One DDR4 SO-DIMM slot |
| Max Memory | Up to 32GB DDR4-2666 |
| Storage | 256GB SSD M.2 2242 PCIe 3.0×2 NVMe |
| Storage Support | Up to two drives, 1x 2.5″ HDD + 1x M.2 2242/2280 SSD • 2.5″ HDD up to 2TB • M.2 2280 SSD up to 1TB • M.2 2242 SSD up to 512GB • Optional Intel Optane Memory integrated with SSD, M.2 |
| Card Reader | 4-in-1 Card Reader |
| Optical | None |
| Audio Chip | High Definition (HD) Audio, Realtek ALC3287 codec |
| Speakers | Stereo speakers, 2W x2, Dolby Audio |
| Camera | 720p with ThinkShutter |
| Microphone | 2x, Array |
| Battery | Integrated 45Wh |
| Max Battery Life | MobileMark 2014: 9 hr (45Wh) |
| Power Adapter | 65W Slim Tip |
| DESIGN | |
| Display | 14″ FHD (1920×1080) IPS 250nits Anti-glare |
| Touchscreen | None |
| Keyboard | Backlit, English (EU) |
| Case Color | Mineral Grey |
| Surface Treatment | Anodizing sandblasting |
| Case Material | Aluminium |
| Dimensions (WxDxH) | 326 x 230 x 17.9 mm (12.8 x 9.06 x 0.70 inches) |
| Weight | 1.5 kg (3.3 lbs) |
| SOFTWARE | |
| Operating System | DOS |
| Bundled Software | Office Trial |
| CONNECTIVITY | |
| Ethernet | 100/1000M |
| WLAN + Bluetooth | 11ax, 2×2 + BT5.0 |
| Standard Ports | · 1x USB-C 3.1 Gen 2 (support data transfer, Power Delivery and DisplayPort)
· 1x power connector · 1x card reader · 1x Ethernet (RJ-45) · 1x USB-C 3.1 Gen 1 · 1x USB 3.1 Gen 1 (Always On) · 1x HDMI 1.4b · 1x headphone / microphone combo jack (3.5mm) · 1x USB 3.1 Gen 1 · 1x USB 2.0 |
| SECURITY & PRIVACY | |
| Security Chip | Firmware TPM 2.0 |
| Fingerprint Reader | Touch Style |
| Other Security | ThinkShutter camera cover |
| SERVICE | |
| Base Warranty | 1-year, Depot |
| Included Upgrade | None |
| CERTIFICATIONS | |
| Green Certifications | · ENERGY STAR 8.0
· EPEAT Silver · ErP Lot 3 · RoHS compliant |
| Mil-Spec Test | MIL-STD-810G military test passed |
